Minimally invasive transhiatal esophagectomy

Introduction

Esophagectomy is used for the treatment of esophageal cancer as well as benign disease. Transhiatal esophagectomy with a cervical anastomosis was reported by Orringer et al. in 1978 (1) and developed into a safe, reproducible, oncologically sound procedure (2,3). The advantages compared to other types of esophagectomies are the avoidance of thoracic incisions, which decreases respiratory complications; and a cervical anastomosis, which is less morbid if it leaks. The main criticism is an incomplete thoracic lymph node dissection, since the mediastinal dissection is performed bluntly. There is no clear difference in oncologic outcomes when comparing the transhiatal esophagectomy to other types.

The first robotic transhiatal esophagectomy was reported by Horgan et al. in 2003, with a robot-assisted abdominal portion and an open cervical portion (4). Initial case series from several institutions showed good surgical and oncologic outcomes using similar approaches (5-7). The video-assisted cervical approach was first described by Bumm et al. in 1993 and allowed a more complete thoracic lymph node dissection. The techniques have been refined using smaller scopes and insufflation (8,9). Transhiatal esophagectomy using combinations of video- and robot-assisted abdominal and cervical approaches (10,11), as well as robot-assisted approaches for both the abdominal and cervical portions, have been described (12,13). Most surgeons favor a small laparotomy to extract the specimen.

In this article, one of the authors (DS Demos) shares his technique in performing a minimally invasive transhiatal esophagectomy, with a robot-assisted abdominal and video-assisted cervical approach. The main advantage of the robot-assisted abdominal approach is the magnified, stereotactic view provided by the camera and the increased dexterity provided by the instruments. Using a camera in both the abdominal and cervical portions of the procedure allows a complete thoracic lymph node dissection.

Preoperative planning

Patients undergo extensive preoperative evaluation with upper endoscopy; computed tomography (CT) scan of the chest, abdomen, and pelvis with intravenous (IV) contrast; fluorodeoxyglucose-positron-emission tomography/CT (FDG-PET/CT) evaluation; endoscopic ultrasound if endoscopic or surgical resection alone may be potential treatment; and bronchoscopy if the tumor is near the airway. Patients who have had preoperative chemoradiation should undergo restaging FDG-PET/CT to ensure that their disease is still resectable. Patients with malnutrition may undergo feeding jejunostomy before neoadjuvant therapy.

Anesthesia and positioning

General anesthesia is induced with single-lumen orotracheal intubation. Only peripheral IV access is needed. Central access, if necessary for any reason, can be established in the right internal jugular vein or either groin. Arterial line placement is not routinely necessary. Upper endoscopy is performed to confirm the location of the tumor. The patient is placed supine with both arms tucked. The neck is extended and rotated to the right to provide access to the left neck.

General conduct

Both the abdominal and cervical portions of this procedure can be performed simultaneously. Operative time is reduced substantially and anesthetic delivery is minimized. This provides for a less-eventful initial postoperative period when perfusion of the conduit and anastomosis is critical.

Robot-assisted abdominal portion

Port placement and docking

Port placement for this portion of the procedure is generally acceptable for all foregut operations. It utilizes all 8-mm ports, essentially in the same transverse plane. We prefer blunt needle abdominal insufflation just below the left costal margin. A camera port is placed two fingerbreadths superior and left of the umbilicus. This can be adjusted for patients with very long torsos. Next, the right subcostal retraction arm port is placed in the same transverse plane as far laterally as is safe. An additional working arm port is placed splitting the difference between the first two. The camera is then placed in one of the right-sided ports to allow clear visualization of the left side. A left subcostal port is placed as far laterally as is safe, again in the same transverse plane as the prior three ports. An 11-mm assistant port is then placed, again splitting the difference between the camera and left subcostal port. Finally, a Nathanson retractor is placed just below the xyphoid process.

The patient is placed in slight reverse Trendelenburg and the robot is then brought into place for docking. Once all ports are docked, the robot arms are separated such that arms 1 and 2 are swung out to the patient’s right, and arms 3 and 4 are swung out to the patient’s left. This is critically important to allow enough space for the surgeon at the neck to proceed with the mediastinal portion of the procedure. The instruments are inserted under direct vision (Table 1).

Technique

The Nathanson retractor is already positioned to elevate the liver from the hiatus. The small grasping retractor is used to elevate the stomach (Figure 1). The vessel sealer is then used to divide the omentum and enter the lesser sac away from the gastroepiploic artery (Figure 2). This dissection is continued up to the hiatus through the short gastric vessels (Figure 3). The stomach is now elevated further anteriorly and any retrogastric adhesions are divided. The left gastric vascular pedicle is identified for later division (Figure 4). Next, an aggressive Kocher maneuver is performed to ensure excellent mobility and reach of the conduit (Figure 5). We generally use the long bipolar forceps in the right hand for this purpose. Upon completion, the pylorus should reach the hiatus without any tension. The gastrohepatic ligament is then opened and dissection is carried through the hiatus into the mediastinum. A Penrose drain is passed around the gastroesophageal junction to allow the bedside assistant to help facilitate this dissection (Figures 6,7). This should connect circumferentially with the dissection performed from the neck. The left gastric artery should be divided at this point. This can also be accomplished before proceeding into the mediastinum. It can be divided either with the vessel sealer or a vascular load on a handheld laparoscopic stapler by the bedside assistant. At this point, the stomach should be completely mobile and this can be tested by observing the stomach while placing traction on the esophagus from the neck.

Figure 1 The robot is docked with all instruments and the Nathanson retractor in view exposing the hiatus.

Figure 2 The omentum is separated from the stomach using the vessel sealer, staying well clear of the gastroepiploic artery.

Figure 3 The short gastric vessels are divided with the vessel sealer.

Figure 4 The left gastric vascular pedicle is exposed.

Figure 5 A thorough Kocher maneuver is performed, often exposing the underlying right kidney.

Figure 6 A Penrose drain is wrapped around the gastroesophageal junction.

Figure 7 The hiatus dissection progresses proximally on the esophagus. The light from the mediastinal dissection camera can be seen anteriorly.

Video-assisted cervical portion

Cervical dissection

A low cervical incision of surgeon preference is created. This can be transverse, one fingerbreadth above the sternal notch, or oblique along the anterior border of the sternocleidomastoid. The platysma is divided, and Lonestar hooks are placed for exposure. These are used specifically because of their low profile, mobility, and versatility. These are adjusted as needed during the exposure of the esophagus. The remainder of the dissection is typically performed bluntly to avoid injury to nerves, and especially the left recurrent laryngeal nerve. Division of the omohyoid muscle is not necessary. The strap muscles are located and followed posteriorly to the cervical spine. The esophagus is circumferentially freed with digital dissection and encircled with a Penrose drain.

Mediastinal dissection

Specific instruments allow the mediastinal dissection to be performed under video assistance (Table 2). The plane posterior to the esophagus is developed first. This prevents dependent collection of blood and fluid if this step was performed later. The Penrose drain is retracted to the patient’s right shoulder, slightly elevating the esophagus anteriorly. The vein scope is introduced posterior to the esophagus, with its longitudinal fibers visible at the top of the screen anteriorly. The LigaSure is then used to dissect the esophagus away from the posterior mediastinum. Great care is taken to cauterize all bridging vessels, as even slight bleeding can be a nuisance. The aorta and azygous vein are typically well-visualized (Figure 8). The thoracic duct can sometimes be seen, but this is not intentionally identified. Dissection is carried as far distally as possible, preferably to the level of the hiatus. At this point, instruments are withdrawn.

Figure 8 The vein harvesting scope is used to retract the esophagus anteriorly, at the top of the screen. The aorta and azygous vein can be appreciated clearly.

Next, the plane anterior to the esophagus is developed. The Penrose is retracted toward the left shoulder. The vein scope is introduced anterior to the esophagus, with its longitudinal fibers now at the bottom of the screen. The LigaSure is similarly used to carefully separate the esophagus from the anterior structures, including the airway and pericardium (Figure 9). This is again carried as far distally as possible. During this portion of the dissection, the scope can compress the airway and communication with the anesthesia team is important.

Figure 9 The vein harvesting scope is passed anterior to the esophagus. The trachea and left mainstem bronchus are clearly identified.

Finally, the anterior and posterior planes are connected by dividing the remaining bridging connective tissue on either side of the esophagus. This is typically best done starting proximal on the esophagus where the two planes are already joined, and continuing them distally (Figure 10).

Figure 10 The anterior and posterior dissections are connected proceeding distally along the left of the esophagus.

Once the esophagus has been fully mobilized, a lymph node dissection is performed. Any visible station 8 lymph nodes that were not mobilized with the esophagus are removed. Occasionally station 3 lymph nodes can be identified and easily removed. A station 7 dissection with this approach is challenging, but can usually be thoroughly accomplished with careful attention to hemostasis. The carina can be located by identification of the apex of station 7 lymph node tissue. The dissection is started in the apex and carried distally along both mainstem bronchi anteriorly to the pericardial surface. The lymph nodes in station 7 are then removed as a packet (Figure 11).

Figure 11 The station 7 lymph nodes are cleared from the subcarinal space.

Anastomosis

The esophagus is divided at the neck, incorporating a very long 1-inch Penrose drain and ensuring 6 cm of esophagus can be brought out of the neck without tension for later anastomosis. The robot is undocked. A small upper midline laparotomy is created and a wound protector inserted. The specimen is delivered through the laparotomy. A gastric emptying procedure of choice may be completed at this point if desired. The conduit is then fashioned beginning on the lesser curve distal to the left gastric artery to include its lymph node supply. A series of heavy staple loads is used to create a 4-cm conduit parallel to the greater gastric curve, stretching the stomach appropriately with each staple load and finally separating the specimen from the conduit. The conduit is then transferred to the neck through the mediastinum in orthotopic position.

We prefer a 2-layer linear stapled anastomosis using a 60-mm staple load and oversewing the staple line. To accomplish this, the ends of the esophagus and gastric conduit are carefully retracted out of the neck adjacent to each other. A small gastrotomy is created and three stay sutures are placed approximating the two openings. The stapler is then inserted with the anvil on the gastric side and cartridge on the side of the esophagus. When the proper alignment has been achieved, the stapler is closed. A series of interrupted silk sutures is then placed along both sides of the stapler from the tip of the stapler to the orifice of the stomach and esophagus, thereby creating an outer handsewn layer. The stapler is then fired, creating the common channel. A nasogastric tube is then passed distally prior to closing the common channel with a Proximate TX stapler (Ethicon, Cincinnati, OH, USA) using a 30-mm green load and oversewing this.

The robot is again docked. The midline laparotomy is closed by clamping the wound protector shut between wet laparotomy sponges to allow for reintroduction of CO₂ insufflation. The conduit’s course through the hiatus is inspected to ensure it appears straight and unkinked. A nonabsorbable polyfilament suture is then used to secure the conduit to both crura. This is performed to prevent both excessive conduit herniation through the hiatus, as well as bowel.

If a feeding tube is desired, the ligament of Trietz is identified and an ideal position for the jejunostomy tube is located for open jejunostomy insertion via the midline laparotomy. We do not routinely place feeding tubes in all esophagectomies as the complication rates from this procedure are low and the postoperative course is generally unremarkable.

Postoperative care

Patients are admitted to the stepdown floor postoperatively. They are maintained on IV fluids, and daily chest radiograph is obtained. The feeding tube, if in place, is used for medications. The nasogastric tube is placed to suction for 24 hours and is clamped on postoperative day 1 if drainage is low. If the conduit is not dilated and the patient experiences no nausea, the tube is removed on postoperative day 2. After evaluation by a certified speech language pathologist, a clear liquid diet is initiated on postoperative day 2 after nasogastric tube removal, and advanced to a soft diet as tolerated. All patients receive a speech therapy evaluation prior to initiating a diet due to higher risk of recurrent laryngeal nerve injury with a neck anastomosis. A contrast esophagram is not routinely obtained. Tube feedings are initiated on postoperative day 2 and advanced as clinically appropriate if a feeding tube was placed. Patients are typically discharged on postoperative day 5.

Conclusions

We describe a technique in performing a minimally invasive transhiatal esophagectomy, with a robot-assisted abdominal and video-assisted cervical approach. The main advantage of the robot-assisted abdominal approach is the magnified, stereotactic view provided by the camera and the increased dexterity provided by the instruments. Using a camera in both the abdominal and cervical portions of the procedure allows a complete thoracic lymph node dissection.
